TM057QDHG03 TIANMA 5.7" 640(RGB)×480 400 cd/m² INDUSTRIAL LCD DISPLAY

Name: TM057QDHG03 TIANMA 57quot 640RGB480 400 cdm INDUSTRIAL LCD DISPLAY
Brand: TIANMA
Price: 1 USD

Wholesale TM057QDHG03 TIANMA 5.7" 640(RGB)×480 400 cd/m² INDUSTRIAL LCD DISPLAY from china suppliers

Brand Name : TIANMA

Model Number : TM057QDHG03

Certification : ISO9001

Place of Origin : JAPAN

MOQ : 1PCS

Payment Terms : TT/PAYPAL/ESCROW/WESTERN UNION

Supply Ability : 100PCS

Delivery Time : 1-2 DAYS

Packaging Details : STANDARD PACKING

MODEL NUMBER : TM057QDHG03

BRAND : TIANMA

SIZE : 5.7INCH

RESOLUTION : 640(RGB)×480 (VGA) 141PPI

BRIGHTNESS : 400 cd/m² (Typ.)

Viewing Angle : 70/70/70/60 (Typ.)(CR≥10)

TEMPERATURE RANGE : Storage Temp.: -30 ~ 85 °C Operating Temp.: -20 ~ 70 °C

SIGNAL LNTERFACE : LVDS

Contact Now

TIANMA TM057QDHG03 Application Details

Basic Information :	Brand		Model	TM057QDHG03
	Type	LCM a-Si TFT-LCD	Used For
	Screen Size	5.7"	Alias	-
Environment :	Storage Temp.	-30 ~~ 85 °C	Operating Temp.	-20 ~~ 70 °C

TIANMA TM057QDHG03 Mechanical Details

Pixel Features :	Resolution	640(RGB)×480, VGA	Dot Pitch(mm)	0.060×0.180 (H×V)
Pixel Features :	Pixel Format	RGB Vertical Stripe	Pixel Pitch(mm)	0.180×0.180 (H×V) [141PPI]
Mechanical Size :	Active Area(mm)	115.2(H) × 86.4(V)	Bezel Area(mm)	118.2(H) × 89.4(V)
Mechanical Size :	Outline Dim.(mm)	144(H) × 104.6(V)	Depth(mm)	12.3/12.8 (Typ./Max.)
Outline Features :	Form Style	Flat Rectangle	Outline Shape
Outline Features :	Aspect Ratio	4:3 (H:V)	Orientation	Landscape type
Mounting :	Without
Other Spec :	Weight	165g (Typ.)	Treatment	Antiglare, Hard coating (3H)

TIANMA TM057QDHG03 Optical Details

Basic Information :	Luminance(cd/m²)	400 (Typ.)	Contrast Ratio	500:1 (Typ.) (Transmissive)
	Viewing Angle	70/70/70/60 (Typ.)(CR≥10)	Display Mode	TN, Normally White, Transmissive
	Best View on	6 o'clock	Response(ms)	20 (Typ.)(Tr+Td)
Color Performance :	White Coordinate	X:0.302; Y:0.329	Display Colors	262K (6-bit)
Color Performance :	Color Temperature	7099K	White Uniformity	1.25/1.33 (Typ./Max.)(9 points)
1931 Color Gamut :	NTSC Ratio	52%	sRGB	71% coverage
	Adobe RGB	54% coverage	DCI-P3	54% coverage
	Rec.2020	39% coverage	Remarks	sRGB (Rec.709, BT.709), Rec.2020 (BT.2020)

TIANMA TM057QDHG03 Electronics Details

Frame Rate :	60Hz
Reverse Scan :	Yes (U/D, L/R)
Time Controller (T-CON) :	Embedded T-CON

TIANMA TM057QDHG03 Interface Details

Signal Electrical :	Voltage Supply	3.3V (Typ.)		Current Supply	195/310mA (Typ./Max.)
Signal Type :	Parallel RGB (1 ch, 6-bit)			Signal Voltage	0≤VIL≤0.3VCC; 0.7VCC≤VIH≤VCC
Interface Features :	Position	-		Type	Connector
Interface Detail :	Brand	Model	Quantity	Pins	Pitch	Pin Configuration
Interface Detail :	STARCONN	089H33-000100-G2-R	1 pcs	33 pins	0.5 mm

TIANMA TM057QDHG03 Backlight Details

Backlight Features:	Shape	3 strings	Type	WLED	Position	Edge light type
Backlight Features:	Replacement	-	Quantity	6S3P	Life Time	50K(Typ.) (Hours)
Interface Features :	Position	-		Type	Connector
Interface Detail :	Brand	Model	Quantity	Pins	Pitch	Pin Configuration
Interface Detail :	JST	SM06B-SRSS-TB	1 pcs	6 pins	1.0 mm
Backlight Driver :	With LED Driver
Driver Electrical :	Voltage Supply	9.0/12.0/21.0V (Min./Typ./Max.)		Current Supply	-
Driver Electrical :	Consumption	1.20W (Typ.)

FAQ:
Q1: What's the quality of your LCD Panel?
A: Various quality such as 100% New & Original OEM New, A Grade LCD, A- LCD Panel etc.
Q2: What is your return and refund policy?
A: We provide you excellent after-sales services, and promise you 6-month warranty after shipping to assure you a stable performance.
Q3: How long is the lead time?
A: The lead time is about 1-3 working days after receipt of payment.
Q4: How can I get the quotation?
A: Please enquire via Skype,Email,Whatsapp or telephone. You will get reply within 24 hours.
